Profile for determining the inclination angle
of freestanding systems
Material
S350GD steel in:
Magnelis®, MagiZinc®, PosMAC coating
Additional information
- extended perforation in the upper part allows for the Installation
of panels of various dimensions without the need to drill
additional holes in the profile
- dense and enlarged perforation in the side enables the Installation
of system within the angle range of 20-35 degrees
- perforation in the lower part allows the bracing profiles to be
screwed on without the need to use additional elements
- made of Magnelis®-coated material with very high corrosion
resistance
For the assembly use SGKFM10x20PV + PW10F Screw Sets
