DUJ...H60 Cable Ladder

1.0

Information

Routing a cable route.

Material

S - Sendzimir method galvanised steel PN-EN 10346:2015-09

Available finishes:

F - hot dip galvanised steel PN-EN ISO 1461:2023-02

E - stainless steel

L - painting in standard RAL colour

Product versions

Add

	Symbol	Catalogue number	Width a (mm)	Length L (mm)	Effective section	Weight (1m) (kg)	Quantity in box (pcs. / m.)
100 mm 4200 mm
	DUJ100H60/3	476010	100	3 000 mm	4,200	1.50 kg	4 / 12 pcs. / m.	Add
200 mm 8400 mm
	DUJ200H60/3	476020	200	3 000 mm	8,400	1.70 kg	4 / 12 pcs. / m.	Add
300 mm 12600 mm
	DUJ300H60/3	476030	300	3 000 mm	12,600	1.90 kg	2 / 6 pcs. / m.	Add
400 mm 16800 mm
	DUJ400H60/6	476040	400	3 000 mm	16,800	2.10 kg	2 / 6 pcs. / m.	Add
500 mm 21000 mm
	DUJ500H60/6	476050	500	3 000 mm	21,000	2.30 kg	2 / 6 pcs. / m.	Add
600 mm 25200 mm
	DUJ600H60/3	476060	600	3 000 mm	25,200	2.50 kg	2 / 6 pcs. / m.	Add
