Cable routing
Material
S250GD steel in:
Magnelis®, MagiZinc®, PosMAC coating
Additional information
- quick and easy assembly
- stable snap connection
- deep hole embossments on the bottom increase the cable tray
strength
- dense perforation with embossments ensures excellent heat
exchange and is designed to allow the installation of the cable
tray on BAKS bracket at any location
- Ø11 holes in the bottom of the cable tray enable suspension on
a threaded rod
Note:
For large orders over 1000 m producing cable trays with
the length of 6 m possible on request
Note:
Producing cable trays with the thickness of 1,0 mm possible
on request
For assembly use SGKFM6x12 or SGM6x12F Screw Sets
