KKJ...H100 Horizontal Bend 90°

1.0
Information

Diversions in cable routing.

Material

S - Sendzimir method galvanised steel PN-EN 10346:2015-09

Available finishes:

F - hot dip galvanised steel PN-EN ISO 1461:2023-02

E - stainless steel

L - painting in standard RAL colour

Additional information

For the assembly use Screw Sets SGKM6x12 or SGM6x12.
In case of special orders please specify dimensions a and b.

Note
Integrated couplers. Assembly without additional couplers.
Product versions
Cable Management Solutions – BAKS Cable Management Solutions – BAKS
Symbol Size a=b (mm) Weight 1 pc. (kg) Catalogue number Quantity (pcs.)
KKJ100H100
Cable Management Solutions – BAKS
100
Cable Management Solutions – BAKS
0.53
Cable Management Solutions – BAKS
112110
Cable Management Solutions – BAKS
1
Add
KKJ150H100
Cable Management Solutions – BAKS
150
Cable Management Solutions – BAKS
0.70
Cable Management Solutions – BAKS
112115
Cable Management Solutions – BAKS
1
Add
KKJ200H100
Cable Management Solutions – BAKS
200
Cable Management Solutions – BAKS
1.02
Cable Management Solutions – BAKS
112120
Cable Management Solutions – BAKS
1
Add
KKJ300H100
Cable Management Solutions – BAKS
300
Cable Management Solutions – BAKS
1.76
Cable Management Solutions – BAKS
112130
Cable Management Solutions – BAKS
1
Add
