KKJ...H50 Horizontal Bend 90°

1.0
Information

Diversions in cable routing.

Material

S - Sendzimir method galvanised steel PN-EN 10346:2015-09

Available finishes:

F - hot dip galvanised steel PN-EN ISO 1461:2023-02

E - stainless steel

L - painting in standard RAL colour

Additional information

For the assembly use Screw Sets SGKM6x12 or SGM6x12.
In case of special orders please specify dimensions a and b.

Note
Integrated couplers. Assembly without additional couplers.
Product versions
Cable Management Solutions – BAKS Cable Management Solutions – BAKS
Symbol Catalogue number Size a=b (mm) Weight 1 pc. (kg) Quantity (pcs.)
KKJ50H50
Cable Management Solutions – BAKS
156205
Cable Management Solutions – BAKS
50
Cable Management Solutions – BAKS
0.21
Cable Management Solutions – BAKS
20
Add
KKJ100H50
Cable Management Solutions – BAKS
156210
Cable Management Solutions – BAKS
100
Cable Management Solutions – BAKS
0.33
Cable Management Solutions – BAKS
20
Add
KKJ150H50
Cable Management Solutions – BAKS
156215
Cable Management Solutions – BAKS
150
Cable Management Solutions – BAKS
0.56
Cable Management Solutions – BAKS
20
Add
KKJ200H50
Cable Management Solutions – BAKS
156220
Cable Management Solutions – BAKS
200
Cable Management Solutions – BAKS
0.77
Cable Management Solutions – BAKS
20
Add
KKJ300H50
Cable Management Solutions – BAKS
156230
Cable Management Solutions – BAKS
300
Cable Management Solutions – BAKS
1.28
Cable Management Solutions – BAKS
10
Add
