Mounting system components to the open side of reinforced and support channels. The use of a nut makes mounting easier and provides additional pressure.
Material
G - galvanised
Available finishes:
F - hot dip galvanised steel PN-EN ISO 1461:2023-02
E - stainless steel
Additional information
– NRS M8/13 and M10/13 nut fits channels: CWD40H22, CWP40H22, CWC40H22, CMD40H22
– NRS M8/33 and M10/33 nut fits channels: CWD40H35, CWP40H35, CWC40H35, CWD40H40, CWP/CWOP40H40, CWC40H40, CMP41H41, CMC41H41
– the use of a spring facilitates mounting by preventing the nut from moving
– selection of hot-dip galvanised bolts to hot-dip galvanised nuts for special order (special design)
– standard hot-dip galvanised bolts do not fit hot-dip galvanised channel nuts
