Cable protection against damage while routing.
Additional tray stiffness at the joint.
Material
S - Sendzimir method galvanised steel PN-EN 10346:2015-09
Available finishes:
F - hot dip galvanised steel PN-EN ISO 1461:2023-02
E - stainless steel
L - painting in standard RAL colour
Additional information
It is neccesary to use it to connect Cable Trays 1.5 mm thickness
For connection of the trays should be used:
- Width 100÷200 mm - min. 4 sets of screw
- Width 300÷400 mm - min. 6 sets of screw
- Width 500÷600 mm - min. 10 sets of screw SGKM6x12
