CTMT80H80 Support Channel - English version - Katalog produktów BAKS

CTMT80H80 Support Channel

3.0
Information

Used for suspending lighting, and as construction
element for installing cable trays, ladders
and bracket.

Material

Steel, strip-galv. acc. to the Sendzimir
method to PN-EN 10346:2015-09
Available to order:
F- steel, hot-dip galv. to
PN-EN ISO 1461:2011, only for orders
up to 300 m
L- powder coating in a full range of colours (PC)

Additional information

Important! In case of large quantity orders available support channels
thickness1.5 and 2.5 mm. For the assembly of support channel
with connectors use Screw Sets SGKM10x20 or SGM10x20

Product versions
Cable Management Solutions – BAKS Cable Management Solutions – BAKS
Symbol Length L (mm) Weight 1 pc. (kg) Catalogue number Quantity (pcs.) 3D file
CTMT80H80/6
Cable Management Solutions – BAKS
6 000 mm
Cable Management Solutions – BAKS
36.86
Cable Management Solutions – BAKS
640860
Cable Management Solutions – BAKS
1
Plik *.std Add
