Cable routing
Material
S - Sendzimir method galvanised steel PN-EN 10346:2015-09
Available finishes:
F - hot dip galvanised steel PN-EN ISO 1461:2023-02
E - stainless steel
L - painting in standard RAL colour
Additional information
Joining cable tray KA... sections together only through the use
of connectors (lack of cut in the flange at the end of side profile). For the
assembly use Screw Sets SGKM6x12 or SGM6x12.
NOTE!
The 1.5 mm thick, stainless steel trays have no upper embossing
(a right angle bend). The covers cannot be snapped closed.
