1.5

Information

Routing a cable route.

Material

S - Sendzimir method galvanised steel PN-EN 10346:2015-09

Additional information

- quick and easy installation
- stable snap-on connection
- connection without Straight Connectors
- New dense perforation of the sides of the ladders enables the installation of Straight Connectors after cutting the ladder at any point.

Product versions

Add

	Symbol	Width a (mm)	Length L (mm)	Effective section	Weight (1m) (kg)	Catalogue number	Quantity in box (pcs. / m.)
100 mm 4200 mm
	DFP100H60/3	100	3 000 mm	4,200	2.42 kg	466111	4 / 12 pcs. / m.	Add
200 mm 8400 mm
	DFP200H60/3	200	3 000 mm	8,400	2.69 kg	466121	4 / 12 pcs. / m.	Add
300 mm 12600 mm
	DFP300H60/3	300	3 000 mm	12,600	2.97 kg	466131	2 / 6 pcs. / m.	Add
400 mm 16800 mm
	DFP400H60/3	400	3 000 mm	16,800	3.24 kg	466141	2 / 6 pcs. / m.	Add
500 mm 21000 mm
	DFP500H60/3	500	3 000 mm	21,000	3.51 kg	466151	2 / 6 pcs. / m.	Add
600 mm 25200 mm
	DFP600H60/3	600	3 000 mm	25,200	3.79 kg	466161	2 / 6 pcs. / m.	Add
