1.5

Information

Routing a cable route.

Material

MC - steel in Mangelis® coating

Additional information

– quick and easy mounting
– connector-less system
– stable snap-in connection
– ladder with rungs suitable for mounting UK/UKO... and UKP... cable clamps

– option E90 for lenghts of 100 – 400 mm

Product versions

Add

	Symbol	Width a (mm)	Length L (mm)	Effective section	Weight (1m) (kg)	Catalogue number	Quantity in box (pcs. / m.)
100 mm 4200 mm
	DFP100H60/3MC	100	3 000 mm	4,200	2.42 kg	4661115	2 / 6 pcs. / m.	Add
200 mm 8400 mm
	DFP200H60/3MC	200	3 000 mm	8,400	2.69 kg	4661215	2 / 6 pcs. / m.	Add
300 mm 12600 mm
	DFP300H60/3MC	300	3 000 mm	12,600	2.97 kg	4661315	2 / 6 pcs. / m.	Add
400 mm 16800 mm
	DFP400H60/3MC	400	3 000 mm	16,800	3.24 kg	4661415	2 / 6 pcs. / m.	Add
500 mm 21000 mm
	DFP500H60/3MC	500	3 000 mm	21,000	3.51 kg	4661515	2 / 6 pcs. / m.	Add
600 mm 25200 mm
	DFP600H60/3MC	600	3 000 mm	25,200	3.79 kg	4661615	2 / 6 pcs. / m.	Add
