1.5

Information

Routing the cable route in halls or areas with limited support structures. The high strength of the trays allows the use of supports even every 8 m.

Material

S - Sendzimir method galvanised steel PN-EN 10346:2015-09

Available finishes:

F - hot dip galvanised steel PN-EN ISO 1461:2023-02

E - stainless steel

L - painting in standard RAL colour

Additional information

– ladder with rungs suitable for mounting UK/UKO... and UKP... cable clamps

– option E – only for lengths up to 3 m – execution with less dense perforation in the bottom of the board (it

is possible to deliver to the customer connected with couplings two 3 m sections giving a length of 6 m)

– for large orders, it is possible to produce ladders with lengths from 2 to 12 m and ladders made of sheet

metal with a thickness of 1.2 or 2.5 mm

– * - product available for order over 200 m

Product versions

Add

	Symbol	Length L (mm)	Width a (mm)	Catalogue number	Quantity in box (pcs. / m.)	Weight (1m) (kg)	Effective section
200 mm 17400 mm
	DSP200H110/3	3 000 mm	200	411721	2 / 6 pcs. / m.	4.98 kg	17,400	Add
	DSP200H110/6	6 000 mm	200	411822	2 / 12 pcs. / m.	4.98 kg	17,400	Add
300 mm 26600 mm
	DSP300H110/3	3 000 mm	300	411731	2 / 6 pcs. / m.	5.26 kg	26,600	Add
	DSP300H110/6	6 000 mm	300	411832	2 / 12 pcs. / m.	5.26 kg	26,600	Add
400 mm 35800 mm
	DSP400H110/3	3 000 mm	400	411741	2 / 6 pcs. / m.	5.55 kg	35,800	Add
	DSP400H110/6	6 000 mm	400	411842	2 / 12 pcs. / m.	5.55 kg	35,800	Add
500 mm 45000 mm
	DSP500H110/3	3 000 mm	500	411751	2 / 6 pcs. / m.	5.84 kg	45,000	Add
	DSP500H110/6	6 000 mm	500	411852	2 / 12 pcs. / m.	5.84 kg	45,000	Add
600 mm 54200 mm
	DSP600H110/3	3 000 mm	600	411761	2 / 6 pcs. / m.	6.13 kg	54,200	Add
	DSP600H110/6	6 000 mm	600	411862	2 / 12 pcs. / m.	6.13 kg	54,200	Add
