KKZMCH50 45° Horizontal Bend

2.0
Information

Changing the direction of the cable route.

Material

F - hot dip galvanised steel PN-EN ISO 1461:2023-02

Available finishes:

E - stainless steel

L - painting in standard RAL colour

Additional information

– to connect the fitting to the tray, use the LCC connector... or a set of LZC... connectors and SGKFM6x12 or SGFM6x12 bolts

Product versions
Cable Management Solutions – BAKS Cable Management Solutions – BAKS
No product version selected
Add
Symbol Width a (mm) Weight 1 pc. (kg) Catalogue number Quantity (pcs.)
Cable Management Solutions – BAKS
50 mm
Cable Management Solutions – BAKS
mm
KKZMC50H50
Cable Management Solutions – BAKS
50
Cable Management Solutions – BAKS
0.95
Cable Management Solutions – BAKS
350905
Cable Management Solutions – BAKS
20 		Add
Cable Management Solutions – BAKS
100 mm
Cable Management Solutions – BAKS
mm
KKZMC100H50
Cable Management Solutions – BAKS
100
Cable Management Solutions – BAKS
1.66
Cable Management Solutions – BAKS
350910
Cable Management Solutions – BAKS
10 		Add
Cable Management Solutions – BAKS
200 mm
Cable Management Solutions – BAKS
mm
KKZMC200H50
Cable Management Solutions – BAKS
200
Cable Management Solutions – BAKS
2.19
Cable Management Solutions – BAKS
350920
Cable Management Solutions – BAKS
10 		Add
Cable Management Solutions – BAKS
300 mm
Cable Management Solutions – BAKS
mm
KKZMC300H50
Cable Management Solutions – BAKS
300
Cable Management Solutions – BAKS
3.22
Cable Management Solutions – BAKS
350930
Cable Management Solutions – BAKS
4 		Add
Cable Management Solutions – BAKS
400 mm
Cable Management Solutions – BAKS
mm
KKZMC400H50
Cable Management Solutions – BAKS
400
Cable Management Solutions – BAKS
4.43
Cable Management Solutions – BAKS
350940
Cable Management Solutions – BAKS
4 		Add
Cable Management Solutions – BAKS
500 mm
Cable Management Solutions – BAKS
mm
KKZMC500H50
Cable Management Solutions – BAKS
500
Cable Management Solutions – BAKS
5.81
Cable Management Solutions – BAKS
350950
Cable Management Solutions – BAKS
2 		Add
Cable Management Solutions – BAKS
600 mm
Cable Management Solutions – BAKS
mm
KKZMC600H50
Cable Management Solutions – BAKS
600
Cable Management Solutions – BAKS
7.37
Cable Management Solutions – BAKS
350960
Cable Management Solutions – BAKS
2 		Add
