Complete floor box ready for mounting in engineered floors, raised floors and concrete screeds. The box with galvanised and stainless steel components is ready for use in wet environments.
S - Sendzimir method galvanised steel PN-EN 10346:2015-09
E - stainless steel
– notches on each side of the metal casing are used, after breaking out, for mounting trunking sections. Ø8 mm holes in the bottom of the housing allow the box to be mounted to the substrate.
– box ready for direct mounting electrical accessories Module 45
– depth of cover fill: W - Carpet, h = 5 mm G - Gres tile, h = 12 mm K - Stone, h = 23 mm
– list of maximum trunking widths to fit the boxes:
– POKZ180H110...E, POKZS180H110...E max. trunking width: 175 mm POKZ205H110...,E POKZS205H110...E max. trunking width: 190 mm POKZ250H110...E max. trunking width: 240 mm POKZ280H110...E max. trunking width: 250 mm
– universal cover allows mounting in carpet, gres tiles and stone
– quick and intuitive mounting box
– various material finishes (aluminium and stainless steel)
– adjustable box height
– breakout holes for trunking with the height of H28, H38 and H48
