1.2

Information

Routing a cable route.

Material

S - Sendzimir method galvanised steel PN-EN 10346:2015-09

Available finishes:

F - hot dip galvanised steel PN-EN ISO 1461:2023-02

E - stainless steel

L - painting in standard RAL colour

Additional information

– option E90 for widths of 100 – 400 mm

Product versions

Add

	Symbol	Catalogue number	Width a (mm)	Length L (mm)	Weight (1m) (kg)	Quantity in box (pcs. / m.)	Effective section
100 mm 2700 mm
	DKD100H45/3N	445110	100	3 000 mm	1.71 kg	4 / 12 pcs. / m.	2,700	Add
	DKD100H45/6N	445210	100	6 000 mm	1.71 kg	2 / 12 pcs. / m.	2,700	Add
200 mm 5400 mm
	DKD200H45/3N	445120	200	3 000 mm	1.94 kg	4 / 12 pcs. / m.	5,400	Add
	DKD200H45/6N	445220	200	6 000 mm	1.94 kg	2 / 12 pcs. / m.	5,400	Add
300 mm 8100 mm
	DKD300H45/3N	445130	300	3 000 mm	2.17 kg	4 / 12 pcs. / m.	8,100	Add
	DKD300H45/6N	445230	300	6 000 mm	2.17 kg	2 / 12 pcs. / m.	8,100	Add
400 mm 10800 mm
	DKD400H45/3N	445140	400	3 000 mm	2.40 kg	2 / 6 pcs. / m.	10,800	Add
	DKD400H45/6N	445240	400	6 000 mm	2.40 kg	2 / 12 pcs. / m.	10,800	Add
500 mm 13500 mm
	DKD500H45/3N	445150	500	3 000 mm	2.62 kg	2 / 6 pcs. / m.	13,500	Add
	DKD500H45/6N	445250	500	6 000 mm	2.62 kg	2 / 12 pcs. / m.	13,500	Add
600 mm 16200 mm
	DKD600H45/3N	445160	600	3 000 mm	2.85 kg	2 / 6 pcs. / m.	16,200	Add
	DKD600H45/6N	445260	600	6 000 mm	2.85 kg	2 / 12 pcs. / m.	16,200	Add
