2.0

Information

Cable routing

Material

Steel, strip-galv. acc. to the Sendzimir
PN-EN 10346:2015-09 (SG)
Available finishes:
F- steel, hot-dip galv.
to PN-EN ISO 1461:2011 (HDG)
E- stainless steel (SS), grade 1.4301 (AISI304),
sections to 3m long.
L- powder coating in a full range of colours (PC)

Additional information

NOTE
Cable ladder with rungs adapted
to fixing Cable Clamps UK/UKO
available upon special order:
- cable ladders 2m long
- cable ladders 150, 250mm wide
- production capability of perforated rungs

NOTE
For horizontal assembly of ladders with rungs directly to the wall
we recommend using ladders with double riveting of rungs
to the side. Installation of the ladder additionally
strengthened with flat bars

Product versions

Add

	Symbol	Width a (mm)	Length L (mm)	Effective section	Weight (1m) (kg)	Catalogue number	Quantity in box (pcs. / m.)
100 mm 4200 mm
	DUC100H60/3	100	3 000 mm	4,200	3.22 kg	466610	4 / 12 pcs. / m.	Add
	DUC100H60/6	100	6 000 mm	4,200	3.22 kg	466710	2 / 12 pcs. / m.	Add
200 mm 8400 mm
	DUC200H60/3	200	3 000 mm	8,400	3.58 kg	466620	4 / 12 pcs. / m.	Add
	DUC200H60/6	200	6 000 mm	8,400	3.58 kg	466720	2 / 12 pcs. / m.	Add
300 mm 12600 mm
	DUC300H60/3	300	3 000 mm	12,600	3.96 kg	466630	2 / 6 pcs. / m.	Add
	DUC300H60/6	300	6 000 mm	12,600	3.96 kg	466730	2 / 12 pcs. / m.	Add
400 mm 16800 mm
	DUC400H60/3	400	3 000 mm	16,800	4.50 kg	466640	2 / 6 pcs. / m.	Add
	DUC400H60/6	400	6 000 mm	16,800	4.50 kg	466740	2 / 12 pcs. / m.	Add
500 mm 21000 mm
	DUC500H60/3	500	3 000 mm	21,000	4.67 kg	466650	2 / 6 pcs. / m.	Add
	DUC500H60/6	500	6 000 mm	21,000	4.67 kg	466750	2 / 12 pcs. / m.	Add
600 mm 25200 mm
	DUC600H60/3	600	3 000 mm	25,200	5.05 kg	466660	2 / 6 pcs. / m.	Add
	DUC600H60/6	600	6 000 mm	25,200	5.05 kg	466760	2 / 12 pcs. / m.	Add
