Assembly of PCS70 and PCS100 base plates
Material
Steel, hot-dip galvanized acc. to
PN-EN ISO 1461:2011
Additional information
- longitudinal perforation enables screw assembly with PCS70
or PCS100 base plates
- Installation of small and medium-sized freestanding systems
without the need for using pile driver
- increased bearing capacity (compaction) of the soil when
screwing in the screw
- hot-dip galvanized material for very high corrosion resistance
For the assmebly of a post with ground screw
use 4 x SGKFM10x30 Screw Sets
