KGJ...H110 Cable Tray

0.7 1.0

KGL...H110 Cable tray H110

KCJ...H110 Cable Tray H110

1.0

Information

Cable routing

Material

S - Sendzimir method galvanised steel PN-EN 10346:2015-09

Available finishes:

F - hot dip galvanised steel PN-EN ISO 1461:2023-02

L - painting in standard RAL colour

Additional information

* - Versions over 300 m available on request.

Possibility of joining cable tray sections together through sliding
one into another and connector-free assembly. For the assembly
use Screw Sets SGKM6x12 or SGM6x12.

Product versions

Add

	Symbol	Catalogue number	Width a (mm)	Length L (mm)	Weight (1m) (kg)	Quantity in box (pcs. / m.)	Effective section
100 mm 10800 mm
	KGJ100H110/3	120210	100	3 000 mm	2.10 kg	4 / 12 pcs. / m.	10,800	Add
150 mm 16300 mm
	KGJ150H110/3	120215	150	3 000 mm	2.36 kg	4 / 12 pcs. / m.	16,300	Add
200 mm 21800 mm
	KGJ200H110/3	120220	200	3 000 mm	2.62 kg	4 / 12 pcs. / m.	21,800	Add
300 mm 32800 mm
	KGJ300H110/3	120230	300	3 000 mm	3.33 kg	4 / 12 pcs. / m.	32,800	Add
400 mm 43800 mm
	KGJ400H110/3	120240	400	3 000 mm	4 kg	2 / 6 pcs. / m.	43,800	Add
500 mm 54800 mm
	KGJ500H110/3	120250	500	3 000 mm	4.70 kg	2 / 6 pcs. / m.	54,800	Add
600 mm 65800 mm
	KGJ600H110/3	120260	600	3 000 mm	5.32 kg	2 / 6 pcs. / m.	65,800	Add
