Cable routing
Material
S - Sendzimir method galvanised steel PN-EN 10346:2015-09
Available finishes:
F - hot dip galvanised steel PN-EN ISO 1461:2023-02
E - stainless steel
L - painting in standard RAL colour
)
Additional information
Joining cable tray sections together only through the use of connectors
(lack of cut in the flange at the end of side profile). For the assembly
use Screw Sets SGKM6x12 or SGM6x12.
NOTE!
The 1.5 mm thick, stainless steel trays have no upper embossing
(a right angle bend). The covers cannot be snapped closed.
